Epoxy Curing Oven Supplied to Electronics Manufacturer
June 26, 2014
Epoxy Curing Oven with Powered Roller Conveyor
- For curing epoxy on electronic modules
- Manually loaded, dual lane indexing chain conveyor system
- Parts carried on trays
- 185º F (85º C) Operating, 212º F (100º C) Maximum
- Maximum product size: 18” w x 19” l x 2.5” high
- Electrically heated: 48 KW on 480/3/60
- Product load: 80 lbs per foot; Dwell time: 40 minutes @ 2.0 FPM
Special Features
- Insulated Walls – 3" insulated walls with an aluminized steel exterior and interior skin within a structural steel frame
- Air Circulation – exhaust fan with manual and top mounted, aluminized steel air supply duct with high velocity nozzles and recirculation fan with TEFC motor.
- Heating Elements – metal sheath electric heating elements installed in the recirculation air stream
Electronic Module
Powered Roller Return Conveyor
Dual Lane Indexing Chain Conveyor
Ref #7446
